AIMB-582

Main Features
  • Supports SUSIAccess and Embedded Software APIs
  • Supports Intel® Xeon®/ Core™ i7/i5/i3 processor with Q77/C216 chipset
  • Four DIMM sockets support up to 32 GB DDR3 1333/1600 MHz SDRAM
  • Supports CRT, DVI, LVDS, DP, eDP (optional) and dual GbE LAN
  • Supports Intel AMT 8.0 and Intel vPro competent
  • Supports PCIE Gen3, USB 3.0, Software RAID 0,1,5,10, TPM 1.2 (Optional)
